MHM Air Handling Unit
MHM · MAH Series · Assembled in Bangladesh
Double-skin modular AHU, 2,000–60,000 CMH, chilled-water coil, EC plug fan option.
Airflow2,000–60,000 CMH
Panel50 mm double skin
Coil4–8 row chilled water
FiltrationG4 to H13
FanEC plug fan option
Warranty12 months
Genuine spare parts and service support
MAH double-skin air handling units use 50 mm PU-injected panels with thermal break, chilled-water cooling coils and backward-curved plug fans. Sections for pre-filter, bag or HEPA filter, cooling, heating and humidification are configured to the room class.
Units are built for garment floors, pharmaceutical clean rooms and hospitals, and are supplied with matching FCU, VRF and ducted-split systems for the rest of the building.
| Model | Airflow (CMH) | Cooling (kW) | Fan motor (kW) | L × W × H (mm) | Weight (kg) |
|---|---|---|---|---|---|
| MAH-02 | 2,000 | 14 | 1.1 | 1800 × 900 × 1000 | 260 |
| MAH-05 | 5,000 | 35 | 2.2 | 2200 × 1200 × 1300 | 480 |
| MAH-10 | 10,000 | 70 | 4 | 2800 × 1600 × 1700 | 820 |
| MAH-20 | 20,000 | 140 | 7.5 | 3600 × 2200 × 2100 | 1450 |
| MAH-40 | 40,000 | 280 | 15 | 4800 × 3000 × 2600 | 2700 |
Ratings at standard conditions. Capacities change with ambient, water temperatures and fouling; ask for a site-specific selection.
Engineered for Bangladesh conditions
Rated for 45 °C ambient, 95% humidity and 380–415 V / 50 Hz supply with wide voltage tolerance.
Genuine parts and service
Spares stocked in Dhaka; breakdown response within 24 hours.
Installed by MHM technicians
Own site team for supply, installation, testing and commissioning.
Energy-efficient design
Premium-efficiency motors and drives reduce running cost from day one.
Remote monitoring ready
Modbus / BACnet interface for BMS integration.
Documented handover
Test reports, O&M manual and drawings supplied with every project.
